High Quality Fine Environmental Friendly Multi
Description
- Overview
- warehouse or checking
- FAQ
Basic Info.
| Model NO. | 6200Y |
| Usage | Pump, Compressor, Valve, Piping |
| Application | Machinery |
| Certification | ISO |
| Color | White |
| Temperature | -50 to +130ºC |
| Density | 1.25g/cm3 |
| Pressure in Rotary | 20bar |
| Speed in Rotary | 20m/S |
| Classification | Pure PTFE Packing |
| Transport Package | Cartons |
| Specification | 3mm-50mm |
| Trademark | TOP SEALING |
| Origin | Zhejiang, China |
| Production Capacity | 60 Tons One Month |
Product Description
1. What is your MOQ?
MOQ may vary by customer's special requirement; we try our best to meet your business requirement.
2. What's your payment terms?
We normally do T/T, and we can also offer western union account for transfer money.
And more flexible payment terms, welcome to have a discuss.
3. Can you provide samples?
A: Yes, we can offer samples, and some samples are free
4. Can you delivery by express?
Yes, we can delivery by any express.
5. When will the sample be ready?
Normally, the sample can be ready in 3 days.
Description:
Pure PTFE yarn including PTFE yarn with lubricant and PTFE yarn without oil. Tenglong PTFE yarn is
made of expanded PTFE resin and high temperature-resistant lubricants through expand treatment,
high tensile strength, low creep and good self-lubrication. The product is a idal used for braiding of pure PTFE packing.
Advantage:
1,Excellent sealing properties
2,Low friction coefficient
3,Low contact temperature
4,Rapid heat lead-off from the contact surface
PTFE Property: Specification:
| PTFE (Polytetrafluoroethylene) | |||
| English | Metirc | ||
| Tensile strength | 1,500-3,000psi | 103-206bar | |
| Flexural modulus | 72,000psi | 4964bar | |
| Izod Impact | Notched | 3.5ft-lbs/in | 7KJ/m2 |
| Heat Deflection Temperature | at 66 psi | 250ºF | 120ºC |
| Continuous Temperature | Maximum | 500ºF | 260ºC |
| Water Absorption | Immersion 24 Hours | <0.01% | |
| Coefficient of Linear Thermal Expansion | 8.9in/in/ºFx10-5 | ||
| Coefficient of Friction | Dynamic | 0.1 | |
| Property | Item | |
| Type | Without Oil | With lubricant |
| Yarn Count | 1700-3500tex | |
| PTFE Content | 94-99% | |
| Oil Content | - | 18 - 24% |
| Breaking force | ≥ 60N | |
| Elongation | > 75% | |
| Operating Temperature | -210~260ºC | |
| Shrinkage | <2% | |
| Chemical Resistance | Excellent | |
| Flammability | Non-flammable | |
